DJI AGRAS MG Series

The Agras MG-1P controller can command up to 5 MG-1P aircrafts simultaneously, dramatically scaling the pilot's ability.  A single flight plan insures a safe and synchronized mission.

The MG-1P’s improved radar system integrates the three high-precision terrain detection radars from previous MG-1S aircraft with an obstacle avoidance radar. This doubles detection sensitivity and allows for multi-directional detection, significantly increasing the aircraft’s ability to sense obstacles and follow terrain automatically. The MG-1P can detect centimeter-wide power lines from up to 15 m away.

Equipped with DJI's advanced A3 Flight Controller, the MG series allows you to fly safely and intuitively. Its algorithm has been optimized for  agricultural utilizations, ensuring stable flight even with sloshing liquids. In addition, the redundant design of the A3 includes dual compasses. If an error occurs in one sensor, the system will automatically switch to the other sensor to continue safe, reliable flight.

High-precision, microwave radars  detect the terrain, allowing the aircraft to adjust its height  approximately. As the radars scan, the DJI Agras is able to perceive the change of terrain,  adjust its altitude and maintain its altitude above the crops.

The Agras spray system allows you to enter the precise volume to be sprayed per hectare.  The MG-1S has two  compatible pumps controlling the front pair and rear pair of nozzles  separately, there are now three spraying  modes available: forward spraying, backward spraying and full spraying.   The MG-1P brings a smoother spray path, curving at the edge of the corner instead of a full stop.

DJI provides a comprehensive spraying management platform for oversight during each spray mission.  You can also  assign fields to each operator and check deployed fields.  By sharing intelligent planning to operators, management for spraying  operations will be more efficient and economic, as operators can avoid  repetitive spraying.
